building control arms: parts and questions.. please

Yea speedway sells the reamers

Originally posted by Dejavu



max, i tried to look up single sheer but it brought up some weird stuff... before i just ask you to explain it to me can you tell me more of what i should be looking for? like "single sheer suspension"? "single sheer mounting"?

thanks



Try this, about halfway down the page.

http://www.roymech.co.uk/Useful_Tables/Screws/Bolted_Joint.html

Originally posted by WickedKustoms



I have all the parts availble for you to do it yourself.I have 2 diff size cross shafts and and bushings and sleeves that slid on the shaft to weld the tubing to for your arms.I also have the screw in style rings for screw in ball joints so you can make them like mustang II arms.Or if you give me the length i can build you a set and send them to you.

just let me no.Its almost just as cheap to buy the arms as it is the parts.

Josh

all i need is the shaft, bushings and sleeves that slid on the shaft to weld the tubing to. do you have toyota shafts? are they machined or are they just stock shafts?

Edited: 12/11/2006 4:37:30 PM by Dejavu



Try this, about halfway down the page.

http://www.roymech.co.uk/Useful_Tables/Screws/Bolted_Joint.html

is sheer the bolts shaft being tested basically menaing the shaft prevents parts from separating by using it

Yes! A bolt in double shear is, at very lest, twice as strong as in single shear. Factory shock mounts that are run in single shear will have a (slightly) engineered bolt with a 5/8" shank. While a double shear shock bolt may be a small as 7/16"

They are a machined shaft.Im not 100% what the toy arm measure from center to center where it bolts to the frame.I have 5.5 inch centers and 6" centers instock.
The cross shafts are 75.00 each.And the bushings and sleeves that slid on them to weld to are 12.00 each.

If you need just the upper arms built to your desired length i can do them between 250.00 and 275.00 depending on how long you need them.

The parts is what cost so much jiging them up and welding them doesnt take nothing.

Let me no if i can help you.

Josh

Originally posted by BioMax



Yes! A bolt in double shear is, at very lest, twice as strong as in single shear. Factory shock mounts that are run in single shear will have a (slightly) engineered bolt with a 5/8" shank. While a double shear shock bolt may be a small as 7/16"

max, thank you very much for the lesson. i would love to learn more things like this( that i should have known)

thanks again.. and thanks for giving me the chance to look it up first before you just told me.

Originally posted by WickedKustoms



They are a machined shaft.Im not 100% what the toy arm measure from center to center where it bolts to the frame.I have 5.5 inch centers and 6" centers instock.The cross shafts are 75.00 each.And the bushings and sleeves that slid on them to weld to are 12.00 each.

If you need just the upper arms built to your desired length i can do them between 250.00 and 275.00 depending on how long you need them.

The parts is what cost so much jiging them up and welding them doesnt take nothing.

Let me no if i can help you.

Joshdo you have any pictures of the shafts and stuff? i am going home and measuring the shaft right now .. ill let you know as soon as i can what i come up with.

it measures 4 and a half center to center....getting and of these machined anytime soon?

I will look into it in the next few days see what its going to run me.

Josh
